XRAY Series
VCSEL laser-line source
XRAY Series
Raysees XRAY series products combine Raysees in-house VCSEL with laser line lens uniquely designed by Raysees optical team. The chip-on-board (COB) packaging and high precision alignment processes ensure volume manufacturing with excellent optical performance and high stability. Raysees XRAY laser line products can be used in various scenarios requiring laser lines with high FOV and high intensity uniformity.
Raysees XRAY sources are mass produced in Raysees own manufacturing lines in Hefei and Shenzhen, under the ISO9001 quality management control.
Product Features
-
Products delivered to
global leading customers -
100%
In-house VCSEL -
Offer custom solutions
rapid response -
In-house packaging
with guaranteed delivery -
Certified workflow
and quality control -
Complete
patent portfolio
Applications
-
Visual inspection
-
Laser obstacle avoidance
-
3D scanning
-
Linear structured light
Raysees patented VCSEL and optics technology
Deliver the best performance line laser source.
XRAY Product Series
|
Product ID
|
Dimension(Customizable)
|
λ(nm)
|
FOV One-Line
|
Line Width@60mA
|
Rated Optical Power @10mA&25℃
|
Operating Temperature
|
|---|---|---|---|---|---|---|
|
LS85-LL6A2A |
5.5*5.5*7.2 |
850nm |
120° |
≤3mm@30cm |
68mW |
-10~+60℃ |
|
LS80-LL6A2A |
5.5*5.5*7.2 |
808nm |
120° |
≤3mm@30cm |
65mW |
-10~+60℃ |
|
LS80-LM1A2A |
5.5*5.5*7.2 |
808nm |
120° |
≤5mm@30cm |
145mW |
-10~+50℃ |
|
LS85-LM1A2A |
5.5*5.5*7.2 |
850nm |
120° |
≤5mm@30cm |
155mW |
-10~+50℃ |
|
LC80-LL6A2C |
Φ8.0*8.5mm |
808nm |
120° |
≤3mm@30cm |
65mW |
-10~+60℃ |
|
LC85-LL6A2C |
Φ8.0*8.5mm |
850nm |
120° |
≤3mm@30cm |
68mW |
-10~+60℃ |
|
LS94-LL5A2A |
5.5*5.5*7.2 |
940nm |
120° |
≤3mm@30cm |
55mW |
-10~+60℃ |
